Application Example Cover part printing process line for IAI EC Compact Type Electric Cylinders – 3 new types added – CRP3(Rod type), CTC (Table type), CGD (Rod with guide type)
This is a digital stall that tells you which part to pick next at a assembly station.
This is a picking device for canned juice displayed on a shelf, using a long 7m actuator.
IAI EC Flat & Short Height, Vertical, Long Stroke Grippers – Low profile, with heights of 30-35mm, Industry-leading performance, Long stroke gripper is also added.
Application Example: ELECYLINDER®︎ Ultra-thin size (20mm width) electric actuator is available now. This is an example of transporting a resin gear and press-fitting it into a motor.
In addition to speed, acceleration and deceleration can be set respectively, enabling shock-less opening and closing while increasing speed.
Positions can be set in increments of 0.01mm, and feedback control of 1,000 times per second ensures repeatable and accurate engraving.
Radial cylinder has a built-in guide, so it can support radial loads without an external guide. ELECYLINDER Radial Cylinder Model, RR6 and RR7 are adopted.
The built-in controller and 24V power supply make it ideal for installation in AGVs. ELECYLINDER Slider Cylinder, S7 is adopted for shooters and inverting.
Sliding bushing construction is resistant to radial impact loads, making it ideal for stopper applications. The 24V power supply allows it to be used in any location.
High thrust type with maximum payload Horizontal 400kg, Vertical 80kg. Vertical mounting is possible even with long strokes, making it ideal for transfer lift applications. (Lifter applications)
The speed can be set in increments of 0.01 mm/s, allowing the conveyor speed to follow the operation. Reduces conveyor downtime.
Since there is no degradation of speed due to aging, the allocation can be performed as set for a long period of time.
The speed feedback of 20,000 times per second ensures that the moving speed is stable and evenly syrupy.
In addition to speed, acceleration and deceleration can be set respectively, thus preventing milk cartons from being knocked over or rolled in.
Driven by 24V power supply, no wiring work is required in the kitchen. The built-in controller helps save space.
Speed feedback of 20,000 times per second ensures stable speed and eliminates misclassification.
Since speed feedback is performed 20,000 times per second, the same timing can be used for each pushing out.
Smooth start/stop by adjusting acceleration and deceleration allows cakes to be transferred to the conveyor without collapsing.
Compact slender type with built-in controller and shortened overall length. Wireless teaching is possible by using the teaching tool TB-03 or Wireless Teaching Controller.
Application Example – Circuit board reverser equipment – Transferring, Turning Around, Inspection, Turning Over – EC Rotary type and Mini Rod type
Clean room specifications correspond to ISO Class 2.5 or 3. Ideal for transport in clean environments.
Clamping force, standby position, and clamping start position can be easily set numerically. Wireless teaching is possible by using the teaching tool TB-03 or Wireless Teaching Controller.
A palm-sized electric actuators are adopted. Up to max. 16 axes can be connected by using the REC controller.
